Galvanize Galvanized Steel Sheet Steel Strip Metal In Coils Qb235
Galvanized Steel Sheet
Product Description of Galvanized Steel Sheet:
What Is Galvanized Steel?
The galvanized coil is a thin steel plate in which a thin steel
plate is immersed in a molten zinc bath to adhere a layer of zinc
to the surface.Galvanized steel is a surface treatment technique
that coats a layer of zinc on the surface of a metal, alloy or
other material for aesthetics, rust prevention, and the like. The
main method used is hot-dip galvanizing. Zinc is easily soluble in
acid and soluble in alkali, so it is called an amphoteric metal.
Zinc hardly changes in dry air. In moist air, a dense zinc
carbonate film is formed on the zinc surface. In the atmosphere
containing sulfur dioxide, hydrogen sulfide and marine, the
corrosion resistance of zinc is poor, especially in the atmosphere
containing high temperature and high humidity containing organic
acid, the zinc coating is easily corroded.
Main Features
1) Corrosion resistance:When zinc is abraded, aluminum forms a
dense layer of alumina that prevents further corrosion of the
corrosive material inside.
2) Heat resistance:Aluminum zinc alloy steel has good heat
resistance and can withstand high temperatures of more than 300
degrees Celsius.
3) Thermal reflexes:The heat reflectivity of Al Zn steel plate is
very high, which is two times that of galvanized steel sheet.
4) economical efficiency:Since the density of 55% AL-Zn is smaller
than the density of Zn, the aluminum-zinc-plated steel sheet is
more than 3% larger than the area of the plated steel sheet when
the weight is the same and the thickness of the gold-plated layer
is the same.
Specification of Galvanized steel sheet:
| Technical Standard | ASTM DIN GB JIS3302 |
| Grade | SGCC SGCD or Customer’s Requirement |
| Type | Commercial Quality/DQ |
| Thickness | 0.13mm-4.0mm |
| Width | 600mm-1500mm |
| Type of Coating | Hot Dipped Galvanized |
| Zinc Coating | 30-275g/m2 |
| Surface Treatment | Passivation/skin pass/non-oiled/oiled |
| Surface Structure | Zero Spangle / Mini Spangle / Regular Spangle / Big Spangle |
| ID | 508mm/610mm |
| Coil Weight | 3-10metric ton per coil |
| Package | Standard export package or customized |
| Hardness | HRB50-71 ( CQ Grade ) |
| HRB45-55 ( DQ Grade ) |
| Yield Strength | 140-300 (DQ Grade) |
| Tensile Strength | 270-500 (CQ Grade) |
| 270-420 (DQ Grade) |
| Elongation Percentage | 22 (CQ Grade thickness less 0.7mm) |
| 24 (DQ Grade thickness less 0.7mm) |
Hot dip galvanizing (HDG):it is one of the common galvanizing methods. The process is to
completely dip iron or steel into molten zinc.
Electro-galvanizing(EG):it is to remove the oil, pickle, and then put into the solution of
zinc salt by electrolysis equipment, and connect the negative
electrode of the electrolysis equipment, place the zinc plate on
the opposite side of the pipe fitting, and connect When the
positive electrode of the electrolysis device is turned on, a layer
of zinc is deposited on the pipe by the directional movement of the
current from the positive electrode to the negative electrode, and
the cold-plated pipe member is processed and then galvanized.
Advantage & Application of Galvanized Steel Sheet:
Corrosion Resistance: the zinc coating surface protects the base steel not only by
providing barrier to corrosion elements,
but also by the sacrificial nature of the coating. Galvanized steel
often remains in working order with little maintenance for
40 years or more.
Production Process:
The production process of hot-dip galvanized sheet:preparation of
original board → pre-plating treatment → hot dip plating →
post-plating treatment → finished product inspection. According to
the habits, the hot-dip galvanizing process is divided into two
categories: off-line annealing and in-line annealing.
What are advantages of galvanized steel?
Because of permanently and successive zinc/iron alloy layers,
galvanized steel offers many benefits than traditional steels.
1.Anticorrosive:13 years in heavy industrial areas,50 years in the
ocean,104 years in the suburbs and 30 years in cities.
2.Cheap:The cost of hot-dip galvanizing is lower than that of other
coatings.
3.Reliable:The zinc coating is metallurgically bonded to the steel
and forms part of the steel surface,so the coating is more durable.
4.Strong toughness:The galvanized layer forms a special
metallurgical structure that can withstand mechanical damage during
transportation and use.
5.Comprehensive protection:Every part of the plated piece can be
galvanized,and is fully protected even in depressions,sharp
corners,and hidden places.
6.Save time and energy:Galvanizing process is faster than other
coating methods.
Packing:
The steel strips supplied according to the standard are usually
applied with common rustproof oil film, which can be swept away
with alkali solution. The supplier guarantees that the oiled
products will be free from rust under normal packing,
transportation, loading and storage conditions within 6 Months, the
approved delivery date. However, product without oil coating can
also be subject subject to statement in the contract reached after
discussion between the user and the supplier.
We offer different modes of transport depending on the customer's
destination: rail transport and ship transport.The Shipping Mark
shall consist of: Trade mark, Seller's name, Product name,
Applicable standards, Specifications, Package No., Contract No.,
Heat No., Weight of zinc film, Color, Production date, Weighing
method, Net weight, Gross Weight, Consignee and Protection symbols,
etc.
